Installation and Removing the Memory Card
Installation of the Memory Card
With the CompactFlash card contacts facing the slot (2), insert the card (4) into
the slot (2) until the eject button (3) pops out of the cover on the front panel.
NOTICE !
There are guides on the sides of the memory card which make it
impossible to insert the card incorrectly.
Removing the Memory Card
Press the eject button (3) and remove the card from the slot (2) by hand.
CAUTION !
To avoid loss of data on the memory card, do not eject the memory card if
the LED (1) next to the slot (2) is illuminated.
Fig. 10b Installation of the Memory Card
10. Memory Cards

CAB A4 Specifications

General

Printer Type	Thermal transfer / direct thermal
Interfaces	USB, Ethernet, RS232
Label Thickness Range	0.05 mm - 0.25 mm
Memory	8 MB Flash
Power Supply	100-240 VAC, 50/60 Hz
Operating Temperature	+5°C to +40°C
Print Resolution	203 dpi
Humidity Range	10-85% non-condensing
