10 10
Withspecialsoftwareorhardwarecongurationsadditionalsymbolsappearonthestartscreen:
Printing on demand
without print job
Printing on demand
within print job
Direct cut
with cutter installed (accessory)
Figure 5 Optional symbols on the start screen
Release printing of a single label within a
print job including cutting...
Release a direct cut without media feed
Table 2 Optional symbols on the start screen
Intheheadlineseveralinformationaredisplayedaswidgetsdependingontheconguration:
Figure 6 Widgets in the start screen
Displays the current data transfer in the form of a falling drop.
The Save data stream function is active Congurationmanual
Allreceiveddataarestoredina.lblle.
Warning ribbon end Congurationmanual
The remaining diameter of the ribbon supply roll undershoots the set value.
SD card installed
USB memory installed
gray: Bluetooth adapter installed, white: Bluetooth connection active
WiFi connection active
The WiFi strength is displayed by the number of white arcs.
Ethernet connection active
USB connection active
abc program active
Clock time
Table 3 Widgets in the start screen
3 Touchscreen-Display
