8.3 Reex Mark Dimensions

Feed direction

virtual label front edge

reex mark

Labelswithreexmarks Endlessmaterialwithreexmarks

Figure 20 Reexmarkdimensions

Dim. Designation Dim. in mm

A Label distance > 2

AZ Distance between print zones > 2

Widthofreexmark > 5

Heightofreexmark 3 - 10

XM Distance mark - middle of paper track -58 - 0

Z Distance virtual label front edge - actual label

front edge

 Adjust software settings

0 up to A / recommended : 0

• Reexmarksmustbeonthebacksideofthematerial(liner).

• Labelsensorforreexmarksonthetopsideonrequest.

• Specicationisvalidforblackmarks.

• Recognition of colored marks may fail.  Preliminary tests are needed.

Table 10 Reexmarkdimensions

Note!

In case of translucent label material, reex marks can be detected not only by the reective sensor but also

by the gap sensor.

8 Media
