8.2 Device Dimensions

Gap sensor

& Reective sensor

Printhead

Tear-off edge

Cut edge

Feed direction

Figure 19 Device dimensions

Dim. Designation Dim. in mm

IT Distance printhead - tear-off edge 13,7

IC Distance printhead - cut edge 20,3

K Print width

203 dpi

300 dpi

108,0

105,7

Distancegap/reectivesensor-middleofpapertrack

i.e.permissibledistanceofreexorcut-outmarksfromthemiddle

of the material

-58 - 0

Distancegap/reectivesensor-

printhead

44,9

Table 9 Device dimensions
