CAB HERMES Q4L User Manual

27
8.2 Device Dimensions
Figure 23 Device dimensions
Dim. Designation Dim. in mm
HERMES Q2 HERMES Q4 HERMES Q4.3 HERMES Q6.3
L R L R L R L R
I Distance printhead - peel-off edge 15
J Distance 1st heating point - material edge
without ribbon saver 203 dpi
300 dpi
600 dpi
-
1,0
1,0
-
1,0
1,0
-
1,0
1,0
-
1,0
1,0
1,0
1,0
-
1,0
1,0
-
1,0
1,0
-
1,0
1,0
-
with ribbon saver 203 dpi
300 dpi
600 dpi
-
-
-
-
-
-
-
1,0
1,0
-
1,0
1,0
2,2
0,0
-
1,6
-0,7
-
0,2
2,9
-
0,2
2,9
-
K
Print width 203 dpi
300 dpi
600 dpi
-
56,9
54,1
-
105,7
105,7
104,0
108,4
-
168,0
162,6
-
SX
Distancegap/reectivesensor-
material edge
i.e.permissibledistanceofreexor
cut-out marks to the material edge
2 - 26 2 - 60
SY
Distancegap/reectivesensor-
printhead
62,5
Table 9 Device dimensions
