2-6 J-Type CCM
J-Type Revision J2005-2
+H, .H\V
See 1.5.13 Connect Seance to console and 1.5.14 Using the Video and Keyboard
Change Over Function with Seance.
+I, )DGHU#FRPPXQLFDWLRQV
See 1.4.1 Audio Bus/Data Bus Connections.
+J,# (YHQWV
The 25 way male 'D-Type' connector labelled
EVENTS
allows the EVENT relay con-
tacts to be wired out for external equipment control. The wiring details are shown in
Table 1
. See SAM manual for details.
Pin no. Relay no. Function
01 1 normally CLOSED contact
14 1 MOVING contact (wiper)
02 1 normally OPEN contact
15 2 normally CLOSED contact
03 2 MOVING contact (wiper)
16 2 normally OPEN contact
04 3 normally CLOSED contact
17 3 MOVING contact (wiper)
05 3 normally OPEN contact
18 4 normally CLOSED contact
06 4 MOVING contact (wiper)
19 4 normally OPEN contact
07 5 normally CLOSED contact
20 5 MOVING contact (wiper)
08 5 normally OPEN contact
21 6 normally closed contact
09 6 MOVING contact (wiper)
22 6 normally OPEN contact
10 7 normally CLOSED contact
23 7 MOVING contact (wiper)
11 7 normally OPEN contact
24 8 normally CLOSED contact
12 8 MOVING contact (wiper)
25 8 normally OPEN contact
13 GROUND
