2-14 J-Type CCM
J-Type Revision J2005-2
51919 7HVW#6\VWHP
This option contains a sub-menu, the options of which appear in 2.3.8 – 2.3.21.
5191: 8VHU#6HWXS
This option contains a sub-menu, the options of which appear in 2.3.22 – 2.3.32.
7HVW#6\VWHP
5191; 6\VWHP#WHVW#²#7HVW#IDGHUV#4
In the system menu, select “
Test System?”
using the Up or Down arrow button.
The display shows “
Test System?”.
■
■■
■
Press [
↵
], followed by the Down Arrow button, until the display shows “
Test fad-
ers 1?
”
■
■■
■
Press [
↵
]. The display changes to “
Testing Faders
”.
The group number display on each of the channels faders increments from 0 to F,
before returning to zero. Each time the fader group display returns to zero, the faders
move on one step in the cycle of:
Everything Off
Mute On
Aux VCA On
Mute & Aux VCA On
Press
[Esc]
to return to the system menu or Down arrow to perform next test.
5191< 7HVW#IDGHUV#5
In the system menu, select “
Test System?”
using the Up or Down arrow button.
The display shows “
Test System?”.
■
■■
■
Press [
↵
], followed by the Down Arrow button, until the display shows “
Test fad-
ers 2?
”
These tests are for the operation of Motor faders only
. If there are no Motor faders in
the console, skip these tests and go to 2.3.11 “
Test keys
”.
■
■■
■
Press [
↵
]. Check that all Motor faders are responding and that their positions are
correctly displayed.
■
■■
■
Using the Left and Right arrow keys, select the fader to test. (Press [
↵
] to go
directly to the channel faders.)
The display shows: “Group 1:0000 00”
The left and right arrow keys may be used to select each fader in turn, group 1
through 16, then channel 1 upwards. The numbers displayed after the colon repre-
sent the raw fader data. If you are experiencing difficulties, please contact CADAC.
519143 7HVW#PRWRU#IDGHUV
In the system menu, select “
Test System?”
using the Up or Down arrow button.
The display shows “
Test System?”.
