MIRIAM-NICE-DIANA-PRETTY-MARY Pag. 89
DESCRIPTION
PRETTY
8,5 kW
DIANA
8,5 kW
MARY
8,5 kW
WIDTH
48,6 cm
55,0 cm
52,0 cm
DEPTH
46,6 cm
46,6 cm
47,0 cm
HEIGHT
95,0 cm
95,0 cm
95,0 cm
WEIGHT
80 kg
73 kg
74 kg
POWER INTRODUCED(Min/Max)
4,4 - 9,7 KW
4,4 - 9,7 KW
4,4 - 9,7 KW
NOMINAL POWER
(Min/Max)
4,1 - 8,5 KW
4,1 - 8,5 KW
4,1 - 8,5 KW
EFFICIENCY (Min/Max)
92 - 88%
92 - 88%
92 - 88%
FUMES TEMPERATURE
(Min/Max)
117 - 208°C
117 - 208°C
117 - 208°C
MAX. FUMES OUTPUT
(Min/Max)
4,08 - 6,6 g/s
4,08 - 6,6 g/s
4,08 - 6,6 g/s
CO EMISSIONS (13% O2)
(Min/Max)
0,034 - 0,019%
0,034 - 0,019%
0,034 - 0,019%
CO2 EMISSIONS
(Min/Max)
7,5 - 10,4%
7,5 - 10,4%
7,5 - 10,4%
AVERAGE CONTENT of CO at
13% O2 (Min/Max)
mg/Nm3
430-236
mg/Nm3
430-236
mg/Nm3
430-236
AVERAGE DUST CONTENT
at 13% O2 (Max)
mg/Nm3
29
mg/Nm3
29
mg/Nm3
29
CHIMNEY DRAUGHT
(Min/Max)
10-11 Pa
10-11 Pa
10-11 Pa
MINIMUM SAFETY
DISTANCE from inflammable
material
30 cm
30 cm
30 cm
SHARED FLUE
NO
NO
NO
SMOKE OUTER DIAMETER
80 mm
80 mm
80 mm
FUEL
Pellet 6 mm
Pellet 6 mm
Pellet 6 mm
PELLET POWER
18200 KJ/Kg
18200 KJ/Kg
18200 KJ/Kg
PELLET HUMIDITY
4.3%
4,3%
4.3%
HOPPER CAPACITY
18 kg
18 kg
18 kg
HEATABLE VOLUME 18/20°C
Coeff
0.045 kW (Min/Max)
98 - 205 m
3
98 - 205 m
3
98 - 205 m
3
HOURLY CONSUMPTION
(Min/Max)
0,91 – 2,01 kg/h
0,91 - 2,01 kg/h
0,91 - 2,01 kg/h
AUTONOMY (Min/Max)
9 - 19,8 h
9 - 19,8 h
9 - 19,8 h
POWER SUPPLY
230V - 50Hz
230V - 50Hz
230V - 50Hz
ABSORBED POWER (Max)
360 W
360 W
360 W
ABSORBED POWER IGNITION
HEATING ELEMENT
300 W
300 W
300 W
MINIMUM OUTDOOR AIR INLET
(USEFUL FINAL SECTION)
80 cm
2
80 cm
2
80 cm
2
