SERVICE & INSTALLATION MANUAL - Emblem
Service Mode
6.7 Media Tab
While a beverage is prepared, a video plays on the screen. The Media tab is used to edit the video
playlists.
To access the screen below, tap in order on the top left, bottom left and bottom right corners of
the screen (see section6) and select the Media tab.
6.7.1 Current Playlist Sub Tab
The Current Playlist sub tab allows to edit the main playlist.
1. This checkbox is used to enable the current playlist.
2. This field is used to change the name of the playlist.
3. List of videos selected for the current playlist.
4. This button is used to add a video from the video storage on the brewer.
5. The source indicates where the playlist comes from. Personalized videos can be added
with Sophia (Optimum license required).
6. This button is used to see a preview of the video.
7. This button is used to save all parameters changes. Any unsaved changes will be lost.
6.7.2 Next Playlist Sub Tab
This sub tab is used to prepare the next
playlist and schedule it to become the current
playlist at a specific time. Parameters are
the same as in the Current Playlist sub tab.
However, a start date and time must be set.
1. Set the start date and time using the
calendar.
2. Add videos to the playlist from the Video
Storage.
7
5
6
1
2
3
4
1
2
