Cafection EMBLEM - ANNEXES; Annex 1: Waste Chute Position

www.cafection.com 800-561-6162
78
DE2112INSA Rev. 0 2022-01
SERVICE & INSTALLATION MANUAL - Emblem
Annex 1
5
1 4
"
4
1 2
"
7"
15
3 4
"
17"
1
1 4
"
MINIMAL
CLEARANCE
12"
13
5 8
"
14
1 2
"
WALLWALL
COUNTERTOP COUNTERTOP
CHUTE HOLE
LEVELLING FEET (4X)
"HOLE EDGES SHOULD BE SEALED WITH SILICONE OR AN APPROPRIATE SEALANT FOR PROTECTION AGAINST WATER DAMAGE"
ANNEX 1 WASTE CHUTE POSITION
