SERVICE & INSTALLATION MANUAL for Cafection’s Total Lite
3.3 Internal view
Filter paper
Soluble mixing
chamber
Brew group
Spout
Waste bin
Main board
(See section4.15)
Front panel
Coffee grinder
(Behind the protector)
COM connection
Fan
Coffee
Hot water
Soluble products
#1 and #2
Soluble
canisters
