16 Technical Data and Installation Diagram
15 Troubleshooting, Error Messages and Fault Repair (continued)
CAFINA c35 1W 12C 12M 12CM c35-mcs c35-mcu c35-cw
Product dispenser Milk cooler
(narrow)
Base
refrigerator
Cup warmer
Coffee yes yes yes yes
Hot water yes yes yes yes
Steam no yes no yes
Milk no no yes yes 4-litre
container
4-litre
container
Hourly output in
cups:
Café Crème 200 200 200 200
Espresso 250 250 250 250
Cappuccino 0 0 200 200
Hot water:
litres/hour
30 40 40 40
Electrical
specifications:
Rated output 2.8 kW 6.8 kW 6.8 kW 6.8 kW 0.15 kW
0.15 kW 0.3 kW
Power connection 230/16 400/16 400/16 400/16
230/10
Ambient specifica-
tions:
Ambient temp. Min. 5 °C
Max. 30 °C
Min. 5 °C
Max. 30 °C
Min. 5 °C
Max. 30 °C
Min. 5 °C
Max. 30°C
Min. 5 °C
Max. 30 °C
Min. 5 °C
Max. 30 °C
Min. 5 °C
Max. 30 °C
Relative humidity Max. 80% Max. 80% Max. 80% Max. 80% Max. 80% Max. 80% Max. 80%
External dimensions:
Width 350 mm 350 mm 350 mm 350 mm 150 mm 350 mm 280 mm
Height
(including bean
hopper)
774 mm 774 mm 774 mm 774 mm 621 mm 218 mm 621 mm
Depth 650 mm 650 mm 650 mm 650 mm 547 mm 650 mm 547 mm
15.2 Error display by means of diagnosis points
On request the c35 is also available with a second grinder.
Diagnosis point Causes of fault Troubleshooting measures
"DP 7" Grounds drawer is full Check grounds drawer
Empty grounds drawer correctly
If the fault persists, contact technical
customer service.
"DP 0" to "DP 6" and
"DP 8" to "DP 31"
System fault Contact technical customer service.
