5
4
1
Designation Machine type
1 Ideal fall height above the bean hopper 180 mm All c35 coffee machines
2 Socket and plug 3N 400 volts 16 amps
Socket and plug 1N 230 volts 16 amps
c35-12C, -12M, -12CM
c35-1W
3 Drain pipe for coffee machine outlet All c35 coffee machines
4 120 mm diameter for supply and drainage All c35 coffee machines
5 150 mm diameter for optional container drop For all c35 with optional container drop
6 Main tap for raw water All c35 coffee machines
7 Supply line G3/8 inches 0.4 MPa (4 bar) All c35 coffee machines
8 Descaling device (Aqua Quell Purity) All c35 coffee machines
253 mm
275 mm
621 mm
542 mm
774 mm
