Instrument Cloning
Instrument Cloning
17
When a satisfactory instrument configuration has been
achieved, either from the initial configuration with the basic
parameter settings, following Autotune or other further
adjustments, these settings can be cloned to other
instruments on the network or saved in a file for later use.
Suites of settings of all the instruments in an application can
similarly be saved to a file making it possible to re-configure
all of the instruments on a machine or process in a matter of
seconds, to optimise them to different task.
Cloning Settings to another instrument on the bus.
Right Click in the display window of the instrument
that settings are to be cloned from.
Click the clone button in any of the pages of
the Internal Parameters for instrument
(n) screen to call up the Clone data
page. The Instruments on line panel will
list all of the instruments on line by it's
Modbus address and either the default
instrument number or name/location
given during Instrument Comms Setting
procedure.
To transfer an instrument or group of
instruments to the Instruments to Clone
panel;
Click anywhere on instrument title, to
highlight, or
Click/hold a group of instrument titles, then
Click the button to transfer the highlighted
instruments to the Instruments to clone
panel, then
Click the OK button to clone them with the
settings from the original instrument.
To Next Page
