CalAmp LMU-30 Series User Manual

CalAmp | LMU-30xx/CVF-3030 & OBD-II Extender Cable Install Guide
Page 4 MBUD-0268v1.4
3.1 LMU-30xx/CVF-3030 Environmental Specifications
The LMU-30xx/CVF-3030 device is designed to operate in the following specified environments.
General Specifications
 Communication modes: cellular and SMS
 Location technology: 50 channel GPS
 Operating voltage: 7-20 VDC
Location Specifications
 Location technology: 50 channel GPS (with SBAS, WAAS, EGNDS, MSAS, GAGAN)
 Location accuracy: 2.0 meter CEP (with SBAS)
 Tracking sensitivity: -160 dBm
 Acquisition sensitivity: -147dBm
Certifications
 Fully certified FCC, CE, IC, PTCRB, carriers
Electrical Specifications
 Operating voltage: 7-20 VDC
 Power consumption:
- Deep sleep: <3 mA @ 12V
- Sleep on network: <11mA
- Active tracking: <140 mA @ 12V
Physical Specifications
 Dimensions approximately 1.7" x 2.5" x 1" (43 x 64 x 25 mm)
Environmental Specifications
 Operating temperature: -22° to + 167° F (-30° to +75° C)
 Storage temperature: -40° to 185° F (-40° to +85° C)
 Humidity: 95%RH @ 50° C non-condensing
 Shock and vibration: SAE J1455
 EMC/EMI: SAE J1113; FCC–Part 15B; industry Canada
 RoHS compliant
