Calculated Industries Construction Master 5 - Rake-Wall Calculations

POCKET REFERENCE GUIDE — 34
Rake-Wall — No Base
Find each stud size in a Rake-Wall with a
peak of 3 Feet 6 Inches and a length of 6
Feet. Use 16 Inches as your spacing
(default):
KEYSTROKE DISPLAY
1. Enter Rise and Run:
o o 0.
3 f 6 i r RISE 3 FEET 6 INCH
6 f R RUN 6 FEET 0 INCH
2. Find Stud Lengths:
∑ RWOC 16 INCH
∑ RW 1 2 FEET 8-11/16 INCH
∑ RW 2 1 FEET 11-5/16 INCH
∑ RW 3 1 FEET 2 INCH
∑ RW 4 0 FEET 4-11/16 INCH
∑ BASE 0 FEET 0 INCH
3. Find Rake-Wall Angle of Incline:
∑ RW 30.26°
Note: To enter a base, enter the base height
prior to pressing the
∑ key ( e.g., 5 f ∑).
STORED
