POCKET REFERENCE GUIDE — 36
(Cont’d)
KEYSTROKE DISPLAY
2. Recall stored 7-1/2 Inch desired Riser
Height and find stair values:
® s R-HT 7-1/2 INCH
s R-HT 7-9/16 INCH*
s RSRS 16.
s R+/– 0 INCH
s T-WD 9-15/16 INCH*
s TRDS 15.
s T+/– 0-1/16 INCH
s STRG 15 FEET 7-5/16 INCH
s INCL 37.27°
*A in the display means the calculated Riser
Height or Tread Width is greater than the stored
desired Riser Height or Tread Width.
STORED
