Your Caldera
®
spa offers numerous ways for you to customize your massage experience. Experiment to find what feels best to you. Try sitting in different seats, adjusting
the diverter valves, air controls, and jet nozzles and turning each pump on or off.
DIVERTER VALVES
The diverter valves on your spa allow you to direct the flow of water from the pumps to various combinations of jets. The functions of
these diverter valves can best be learned by experimentation as follows:
Set all air controls to the “ON” position by rotating counterclockwise.1.
Turn on both pumps.2.
Turn the handle on each diverter valve and see which groups of jets are affected. (Note that you can adjust the diverter valves to any 3.
position between the two possible extremes to achieve the jet pressure that feels best to you.)
IMPORTANT: Your spa is not designed to provide full power to all jets when the diverter valves are in the “mid” position. However, with
the diverter valve in this position, you may increase the power to selected jets by rotating the face of the AdaptaFlo
™
and AdaptaSsage
™
jets to close the ones that are not in use.
TIP: Turn both pumps on and place the diverter valves to the “Mid-Position”. Then experiment with each of the air controls to see their effect.
ACQUARELLA
®
WATERFALL VALVE
Your spa is equipped with the Acquarella waterfall feature. It is activated by turning on Jet Pump 2 (either low or high speed). The flow is
regulated by turning the waterfall valve on the inside wall of the spa.
NOTE: On the Cantabria™, Pump 1 activates the waterfall to the left of the main control panel, and Pump 2 activates the waterfall to the
right of the main control panel.
ATLAS
®
NECK JET VALVE
The Utopia spas are equipped with 4 directional neck jets located in the EcstaSeat
®
. The flow of the neck jets is regulated by turning the Atlas NeckJet valve on the
inside wall of the spa.
AIR CONTROLS
Each jet system has its own air control. These allow you to change the power of the jets by regulating the amount of air that is mixed with
the water coming out of the jets.
HYDRO JETS
AdaptaFlo Jets - These jets allow you to redirect the jet stream by changing the position of the nozzle.
AdaptaSsage Jets - These jets provide a rotating massage pattern.
The face plates in the AdaptaFlo jets and the AdaptaSsage jets are interchangeable. To remove a AdaptaSsage face plate, turn it counter-clockwise until it stops turning.
Turn the face once more until you hear a clicking noise, push it in, and then pull it straight off. Install the face plate by snapping it into place. Additional AdaptaSsage
dual-port nozzles are available from your Caldera dealer.
Both the AdaptaFlo and AdaptaSsage jets allow you to regulate the force of the massage. Rotate the fascia ring counter-
clockwise to reduce the force, or clockwise to increase the force. Notice that turning off the flow to some jets increases
the flow to the other jets. To avoid damage to your spa’s plumbing and components, do not turn off more than half of
these jets at the same time.
CUSTOMIZING YOUR MASSAGE
17
AdaptaFlo Jet
AdaptaSsage Jet
