Proprietary*Information:*Not*for*use*or*disclosure*except*by*written*agreement*with*Calix.*
"!#$%&'(!)%%!*&+,-.!*/./01/2(!
Connecting+the+E7420+Line+Interfaces+
This section describes how to connect the Calix E7-20 line interfaces to the network.
'S2%FF%-L!/D4!'()*+!%-/47Q#I4!F07/.!
Calix E7-20 line cards use pluggable transceiver modules to provide interface connections,
but the cards do not ship equipped with modules. You must install pluggable modules into
the cards to equip the ports.
Calix offers a full suite of optical and copper pluggable modules to support a wide array of
applications. The E7-20 10GE and GPON ports require only Calix-supplied modules, but
E7-20 GE ports can use SFP modules from Calix or other suppliers, with some restrictions.
Refer to the E7-20 Product Planning Guide for complete details.
Note: When using SFP modules not supplied by Calix, you must use modules that comply
with the SFP Transceiver MultiSource Agreement (MSA). See the Small Form Factor (SFF)
committee INF-8074i specification Rev 1.0 for details.
Pluggable modules are available to support different facility types and connectors:
10GE (10 Gbps) optical
10GE (10 Gbps) copper
GE (1000 Mbps) dual-fiber and single-fiber modules
FE (100 Mbps) dual-fiber and single-fiber modules
1000/100BaseT copper modules
GE (1000 Mbps) dual-port, single-fiber modules
_)%%!<J:.!9D.-!@/!#%$..!U!%$. /0 !2 /1 &6 / . !&5 !$ 6 6 40 2 $5 6 / !O&-,!JL)!0/+D%$-&45 !> U # J*!UI3I(UIS!UI3I (U U S!$ 5 2 !B7 # !? I V > K=U(!
,-./#$$%-L!H$2LL#6$4!C7#-.I4%@47!W032$4.!
Install pluggable transceiver modules into the E7-20 line cards to equip the ports for optical
or copper interface connections.
