! G!
!
Proprietary*Information:*Not*for*use*or*disclosure*except*by*written*agreement*with*Calix.*
"!#$%&'(!)%%!*&+,-.!*/./01/2(!
'()*+!570-/!
The Calix E7-20 line cards, SCP cards, and fan tray install into the front of the E7-20 shelf.
When equipped with line cards, the E7-20 front panel also terminates all system line
interfaces (fibers). The E7-20 fan tray is equipped with Craft Ethernet and serial ports for
management and features several system status indicators. The front of the chassis also
includes a removable fiber management system.
'()*+!?4#7!
The E7-20 power inputs (A/B), ground, Craft management, and BITS timing interfaces are
located on the rear of the E7-20 shelf.
?#IY!N02-/%-L!0F/%0-.!
The E7-20 provides two mounting options:
!! Standard US Telco with 5-inch maximum protrusion from the front of the rack
mounting rails to farthest forward point of the equipment, all cables included.
!! Mid-mount with 10-inch maximum protrusion from the front of the rack mounting rails
to farthest forward point of the equipment, all cables included.
