Pro-Pac PPT30M/MY
DIMENSIONS IN mm ISSUE 1
ALLOW 500mm FOR ACCESS TO SERVICE PANELS
WATER CONNECTIONS 2" UNION SOCKETS CONDENSATE 1.5"
CONSOLE
HP SWITCH
LP SWITCH
(AUTO RESET
LP SWITCH ON
Y MACHINES)
AIR IN
MAINS IN
AIR OUT
SERVICE
PANEL
SERVICE
PANEL
ELECTRIC
BOX
ACCESS
IO
*683
*FIXING CENTRES TO SECURE MACHINE
780
SERVICE
PANEL
1080
232
692
460
176
WATER
OUT
WATER
IN
1585
1486
*880
814
POSITION OF CONDENSATE
DRAIN IN BASE OF MACHINE
617
POSITION OF CONDENSATE
DRAIN IN BASE OF MACHINE
SERVICE
PANEL
NOMINAL FAN
DIAMETER 500
SERVICE
PANEL
SERVICE
PANEL
752
316
38
SD566252 ISSUE 51
PR0-PAC SYSTEM OWNER INSTALLATION MANUAL
