Calorex Pro-Pac 45 - Page 46

Pro-Pac PPT140MY
DIMENSIONS IN mm
ISSUE 1
LEAVE 500mm CLEARANCE FOR SERVICE PANELS
WATER CONNECTIONS 4" BSPM CONDENSATE 1½" BSPM
LP
SWITCH
(AUTO
RESET
LP
SWITCH
(AUTO
RESET)
SERVICE
PANEL
SERVICE
PANEL
SERVICE PANEL
NOMINAL FAN
DIAMETER 815
821
514.50
1437.50
WATER
OUT
WATER
IN
2146
2250
HP
SWITCH
SERVICE PANEL FOR
ELECTRIC BOX ACCESS
1650
SERVICE PANEL
CONSOLE
HP
SWITCH
0 1
*1616
1290
CONDENSATE OUT
POSITION IN BASE
FAN 2
FAN 1
AIR IN
AIR OUT
712
1340
*1562
CONDENSATE OUT
POSITION IN BASE
*FIXING CENTRES TO SECURE MACHINE
252
AIR IN
408
504
DRAIN
DOWN
SERVICE PANEL
CONDENSATE
OUT POSITION
IN BASE
254
254
46
SD566252 ISSUE 51
PR0-PAC SYSTEM OWNER INSTALLATION MANUAL
