Pro-Pac PPT140M
DIMENSIONS IN mm
ISSUE 1
LEAVE 500mm CLEARANCE FOR SERVICE PANELS
WATER CONNECTIONS 4" BSPM DRAIN DOWN 2" CONDENSATE 1½" BSPM
SERVICE
PANEL
SERVICE
PANEL
SERVICE PANEL
NOMINAL FAN
DIAMETER 815
821
514.50
1437.50
WATER
OUT
WATER
IN
2146
2250
HP SWITCH
LP SWITCH
SERVICE PANEL
ELECTRIC BOX ACCESS
1650
SERVICE PANEL
CONSOLE
HP SWITCH
LP SWITCH
0 1
*1616
1290
CONDENSATE OUT
POSITION IN BASE
FAN 2
FAN 1
AIR IN
AIR OUT
712
1340
*1562
254
*FIXING CENTRES TO SECURE MACHINE
252
AIR IN
1236
504
DRAIN
DOWN
SERVICE PANEL
CONDENSATE
OUT POSITION
IN BASE
254
CONDENSATE
OUT POSITION
IN BASE
