I-MAT_Ed6 - Operating Instructions Page 49 / 164
SA18 Fieldbus Type
0 = oFF
1 = Modb
2 = PbuS
3 = PnEt
oFF
SA19 Comunication Big Endian / Little Endian
0 = Big Endian
1 = Little Endian
0
SA20 Enable timeout (s)
Off
On
Off
SA21 Comunication timeout (s) 1 – 10 5
SA22 Device Address 0 – 255 0
SA23 Baudrate
0 = 9600
1 = 19200
2 = 38400
3 = 57600
4 = 115200
0
SA24 Parity
0 = None
1 = Odd
2 = EVEn
0
16.4. Parameter PC – Pressure constant settings
N° Description Parameter values Standard Modications
PC01
Minimum run frequency for primary set-
point
(Hz) Auto auto
PC02 Frequency before stop for primary set-point (Hz) Auto, Man Auto
PC03
Minimum run frequency for secondary set-
point
(Hz) Auto
PC04
Frequency before stop for secondary set-
point
(Hz) Auto
PC05 Time before stop (s) 30
PC06 Set-point pressure step up (bar) 0,3
PC07 Pressure step up ramp (bar/s) 0,3
PC08 Pressure step up time (s) 3
PC09 Restart fall pressure set-up (bar) 0,3
PC10 System dynamic 3
PC11 Pressure PID (proportional gain) 3000
PC12 Pressure PID (integral time constant) 400
PC13 Pressure PID (derivative time constant) 1000
PC14 Cascade mode start fall pressure set-up (bar) 0,3
PC15 Cascade mode restart delay (s) 10
PC16 Cascade mode fall pressure limit set-up (bar) 0,6
16.5. Parameter PP – Proportional pressure settings
N° Description Parameter values Standard Modications
PP01 Percentage of the pressure with zero ow (%) 50
PP02
Minimum run frequency proportional
pressure
(Hz) auto
PP03
Frequency before stop proportional
pressure
(Hz) auto
PP04 Time before stop (s) 30
PP05 Set-point pressure step up (bar) 0,3
PP06 Pressure step up ramp bar/s 0,3
PP07 Pressure step up time (s) 3
PP08 Restart fall pressure set-up (bar) 0,3
PP09 System dynamic 3
PP10 Pressure PID (proportional gain) 3000
PP11 Pressure PID (integral time constant) 400
PP12 Pressure PID (derivative time constant) 1000
PP13 Cascade mode start fall pressure set-up (bar) 0,3
PP14 Cascade mode restart delay (s) 10
PP15 Cascade mode fall pressure limit set-up (bar) 0,6
