12
Pump and Control Box Placement Diagrams
C
93"
[236]
151"
[384]
31"
[79]
26"
[66]
STUB UP
Note: All Spas including swim spas require a minimum of 3 feet clearance on all sides
for accessibility for technicians to perform repairs or maintenance. Service providers
may charge a fee for poor access which would require movement of the spa by crane
or removal of objects/decks obstructing access.
F-1325 & F-1325X
Control Box
Pump
