Camco Vortex Series - Operating the Amplifier

3 INSTALLATION
+
+
+
Vortex 3 Quadro
≥ 2 Ω
≥ 8 Ω
ch A
ch B
ch C
ch D
+
+
Vortex 3 Quadro
≥ 8 Ω
≥ 8 Ω
ch A
ch B
ch C
ch D
USER MANUAL
VORTEX 3 QUADRO
P.18
USER MANUAL
VORTEX 3 QUADRO
P.19
3.9.5.2 Mono-Bridge / Mono-Bridge
With its mode selectors set to Mono-Bridge the VORTEX 3 QUADRO is able to
control high impedances.
3.9.5.3 Parallel-Mono / Mono-Bridge
It is also possible to set one amplier to Parallel-Mono and the other to Mono-
Bridge operation.
