8 MEASUREMENTS
-20
-30
-40
-50
-60
-70
-80
-90
-100
-110
-120
dB
100u 200u 500u 1m 2m 5m 10m 20m 50m 100m 200m 500m 1 2 5
Vrms
1k
800
600
400
200
0
V
20 50 100 200 500 1k 2k 5k 10k 20k
Hz
300m
200m
100m
50m
20m
10m
5m
2m
V
20 50 100 200 500 1k 2k 5k 10k 20k
Hz
-40
-50
-60
-70
-80
-90
-100
-110
-120
dBr
20 50 100 200 500 1k 2k 5k 10k 20k
Hz
USER MANUAL
VORTEX 3 QUADRO
P.32
USER MANUAL
VORTEX 3 QUADRO
P.33
Figure 8.5
Output Impedance vs. frequency @ 1 Amp RMS injected current
equivalent 11 mΩ + 2,1 µH (Measurements of a typical performance)
Figure 8.7
Damping factor into 8 Ω vs. frequency
equation: damping factor = loaded impedance / amplier output impedance
(Measurements of a typical performance)
Figure 8.6
THD+N @ 1 kHz, 4 Ω load vs. input voltage
(Measurements of a typical performance)
Figure 8.8
CMRR
(Measurements of a typical performance)
