CAME A3000

Page 14 - Manual FA01810-EN - 06/2022 - © CAME S.p.A. - The contents of this manual may be changed at any time and without notice. - Translation of the original instructions
With the gate closed, fasten the anchoring plate and bracket to the gate.
The gate bracket and pillar bracket must be aligned horizontally.
Please respect measurement E as listed in the table.
