INSTALLATION
The following illustrations are examples only. The space available for fitting the operator and accessories varies depending on the area where it is
installed. It is up to the installer to find the most suitable solution.
The drawings refer to a gearmotor installed on the left-hand side.
Preliminary operations
Prepare the junction boxes and corrugated tubes you need for the connections from the junction pit.
The number of tubes depends on the type of system and the accessories that are going to be fitted.
