Page 2 - Manual FB00884-EN - vers. 1 - 09/2017- © Came S.p.A. - The contents of this manual may be changed, at any time, and without notice.
General precautions
• IMPORTANT! Important safety instructions: READ CAREFULLY!
• Installation, programming, commissioning and maintenance must only be carried out by expert qualified tech-
nicians in full compliance with the regulations in force.
• Wear anti-static shoes and clothing if working on the electronic circuit board.
• Keep this precaution information.
• Disconnect the power supply during any cleaning or maintenance work.
• The product must only be used for the purpose for which it was expressly designed. Any other use is to be
considered dangerous.
• The manufacturer declines all liability for any damage as a result of improper, incorrect or unreasonable use.
OPERATIONS FOR REMOTE CONTROL OF CALL BUTTONS
Manual configuration of terminals
and as call inputs 1 and 2
Short circuit the terminals ( and ), press and hold the two call buttons on the unit, and power the device.
The unit restarts. The procedure has been completed successfully.
Remove the short circuit and connect the additional N.O. buttons to the terminals
and .
BUTTON NUMBERING
