- 05/2015 - © Came S.p.A. - The manual's contents may be edited at any time without notice.
5.7 Manually releasing the gearmotor
- Insert the trilobed key into the lock, push it in and turn it clockwise ....
5.6 Mounting the endstop fins
Place the endstop fi ns onto the rack and secure them using a 3 mm Allen wrench. Their positioning limits the gate run.
Note: the gate schould not slam against the mechanical stop, when opening or closing.
Mechanical stop
Trilobed key
Knob
..... open the small door and turn the release handle clockwise.
WARNING: opening the door
will disengage the motor (i.e. it will
not function). To operate the motor
the release mechanism must be
fi rmly fastened.
