0.2 03/2010 © CAME cancelli automatici s.p.a. - The data and information reported in this installation manual are susceptible to change at any time and without obligation on CAME cancelli automatici s.p.a. to notify users.
ENGLISH
Similarly, open the bar and adjust the free damper, to regulate the horizontal position (= closing).
Warning! The bar’s stop position is preceded by the slowing phase by means of a tab and spring system that activates the slowing-down microswitch prior to
the bar’s total stop.
5.8 End stop adjustment
N.B.: perform this procedure after fi nishing the electrical connections.
Close the door and power up the system, activate the barrier to make sure it is parallel with the closed and at about 89° when open.
Warning! For greater safety and better unit performance, the bar’s opening and closing operations should be carried out with the inspection hatch closed!
If any adjustment of the vertical position (= opening) is needed, open the
inspection door and rotate the free damper clockwise (to increase the bar’s
run) or counter-clockwise (to decrease the run).
