CAME PS ONE SERIES User Manual

1 2 3 4 5 6
7
8
11
10
91213
14
16
15
p.
14
14 -
Manual code:
119GF88
119G F8 8 ver.
1.0
1.0 05/2012
© CAME Cancelli Automatici S.p.A. - The data and information in this manual may be updated at any time by Came Cancelli Automatici S.p.A. which is under no obligation to notify said updates.
ENGLISH
8 Cash-register board - description
1. VAC power supply inputs
2. Inter lighting connection terminal
3. Fans and heater connection terminals
4. Remote alarm output terminal
5. Terminal Restart relay switch
6. Network up sensor terminal
7. Siren sensor alarm connection terminal
8. Cash-register top element LED connection terminal
9. Front board data connection
10. Input status signalling LED light
11. Operating LED light
12. Input terminals
13. Vcc power supply input
14. Ground connection
15. Fans and heater fuse
16. Internal lighting fuse
