CAME PS ONE SERIES User Manual

L3 L4 L5 L6
p.
21
21 -
Manual code:
119GF88
119G F8 8 ver.
1.0
1.0 05/2012
© CAME Cancelli Automatici S.p.A. - The data and information in this manual may be updated at any time by Came Cancelli Automatici S.p.A. which is under no obligation to notify said updates.
ENGLISH
11.1 Connecting coils
11.2 Connecting barriers
- On the left side of the post, find the bi-channel sensor, then
connect up the coils (metal mass detector sensors).
Entry coil
Exit coil
- Remove the container cover to access the electrical board
on the post.
11 Entry unit - exit unit - electrical connections
