12 04/20109 © CAME cancelli automatici s.p.a. - The data and information reported in this installation manual are susceptible to change at any time and without obligation on CAME cancelli automatici s.p.a. to notify users.
ENGLISH
Terminals for powering the following accessories:
- 24 V AC (normally alternated power)
- 24 V AC (continuous power) when the emergency batteries
are in operation.
Overall power allowed: 34 W
Power supply
230 V AC 50/60 Hz
6.4 - POWER SUPPLY TO AND ACCESSORIES
6.3- SIGNALLING AND LIGHTING DEVICES
Open gate indicator-light
(socket rating: 24 V - 3 W max.).
- Turns on when the gate is ajar or
open. It turns off when the gate is
closed.
(Also see Chapt. 6.5)
Signal Flasher
(socket rating: 24 V - 25 W max.)
- Flashes during opening and
closing phases
