Cameron TK User Manual

ENGINEERED & PROCESS VALVES
01/2011 / IOM-TK-TMBV-01
3
Installation, Operation and Maintenance Manual
SCOPE
The TK Valve is designed and manufactured to provide trouble free service and a long service life. This
manual provides the relevant information that is required for the successful operation of standard and fire
safe (end entry) TK Valves. Please note the drawings within this manual are for illustration purposes only.
API-6D Valve Pressure Class
Valve Size in Inches
1.5” 150 300 600 900 1500 2500
2” 150 300 600 900 1500 2500
3” 150 300 600 900 1500 2500
4” 150 300 600 900 1500 2500
6” 150 300 600 900 1500 2500
8” 150 300 600 900 1500 2500
10” 150 300 600 900 1500 2500
12” 150 300 600 900 1500 2500
14” 150 300 600 900 1500 2500
16” 150 300 600 900 1500 2500
18” 150 300 600 900 1500
20” 150 300 600 900 1500
22” 150 300 600 900 1500
24” 150 300 600 900 1500
26” 150 300 600
28” 150 300 600
30” 150 300 600
32” 150 300 600
34” 150 300 600
36” 150 300 600
API-6A Valve Pressure Class
Valve Size in Inches
2-1/16” 2000 3000 5000
3-1/8” 2000 3000 5000
4-1/16” 2000 3000 5000
7-1/16” 2000 3000 5000
9” 2000 3000 5000
11” 2000 3000 5000
