ENGINEERED & PROCESS VALVES
01/2011 / IOM-TK-TMBV-01
5
Installation, Operation and Maintenance Manual
Sizes:
Studded Outlet - Non-Trunnion (Seat Supported Ball)
2” x 1.5” class 150
2” x 2” class 150
3” x 2” class 150
Studded Outlet - Trunnion Mounted Ball
3” x 3” class 150
4” x 4” class 150
6” x 4” class 150 (short pattern)
Flanged End - Non-Trunnion (Seat Supported Ball)
1.5” X 1.5” class 1500
2” x 1.5” class 300, 600, 900 & 1500
2” x 2” class 300
3” x 2” class 300
NOTES ITEM QTY DESCRIPTION
100 1 Body
1 122 * Body Socket Head Cap Screws
2 123 * Body Studs
2 124 * Body Stud Nuts
142 1 Body Drain Plug
143 1 Body Sealant Fitting
144 1 Body Ball Check Valve
181 1 Body Adapter Bore Fire Seal
182 1 Body Bonnet Bore Fire Seal
5 183 1 Body Trunnion Bore Fire Seal
202 1 Adapter (Closure)
221 1 Adapter O-ring
341 1 Gear Bonnet
352 * Gear Bonnet Socket Head Cap Screws
371 1 Gear Bonnet O-ring
372 1 Gear Bonnet Zerk Fitting
5 400 1 Trunnion Flange
5 451 4 Trunnion Flange Hex Head Cap Screws
500 1 Ball
3 601 2 Seat Insert
610 2 Seat
611 2 Seat Holder O-ring
621 2 Seat Holder Flat Spring
630 2 Seat Holder Fire Seal
631 2 Seat Holder Fire Seal Compression Ring
721 1 Gear Stem
4 722 1 Gear Stem Key
741 2 Stem O-ring
762 1 Stem Thrust Washer
780 1 Stem Fire Seal
781 1 Stem Fire Seal Compression Ring
5 820 1 Trunnion
5 840 1 Trunnion Bushing
5 860 1 Trunnion Thrust Disc
Notes:
1. Are only used on the Studded Outlet Design.
2. Are only used on Flanged-End Design.
3. Seat Inserts are only available for soft seated valves. Metal seated valves are coated with Tungsten Carbide.
4. Are only used on gear operated valves. Lever operated valves do not require a key.
5. Only used on trunnion mounted ball valves. See figure 2 for details.
* Quantity may change depending on valve size.
