CandCNC THC Sensor PWM - Page 15

CandCNC
Page 15
CONNECTING to YOUR PLASMA
RAV-01 Raw Arc Voltage Divider Option
E
Module
1
CandCNC RAW ARC VOLTS Voltage divider card
Plexiglas
Safety
Shield
RJ45 (Cat5) cable to
DTHCII Module
Divided volts from
CandCNC Raw Arc
Volts card
RAV-02 Mounted inside Plasma UNIT.
THC SENSOR PWM MODULE
Mounted outside plasma unit
Connections for PWM II MODULE are the SAME
SENSORSENSOR
PWM PWM
Digital Plasma Module
Torch
ON
+5
To DCP-01
To DTHC Module
Test
Active
ARC OK
To Plasma
Cable
Input JACK
Divided Volts
CandCNC
Arc OK
(Transfer)
TORCH
SWITCH
Front
Arc OK
+12 PWR
To CPC or RAV-01
Later version RAV-02
Note: Same wire colors
are used on the PWM II
