CandCNC
Page 21
CandCNC
CONNECTING TO HAND TORCH SWTICH
WIRES FROM RAV-01
SWITCH WIRES FROM
PLASMA HAND PIECE
RAV-02 Raw Arc Volts CARD
RAV-02
Later version RAV-02
USING THE RAV-01 TO FIRE THE TORCH
(for plasam units with no external connector
to fire the torch or with a hand torch)
E
1
Volts card
ALTERNATE METHOD TO FIRE HAND TORCH IF NOT
USING RAV-01 CARD
Use the same two wires on the 4 pin connector for
the PWM Module REV 21
SENSORSENSOR
PWM PWM
Digital Plasma Module
Torch
ON
+5
To DCP-01
To DTHC
Module
Test
Active
ARC OK
To Plasma
Cable
Input JACK
Divided Volts
CandCNC
Arc OK
(Transfer)
TORCH
SWITCH
Arc OK
+12 PWR
RJ45 (Cat5) cable to
DTHCIV Module
To Next Page
