PC400 / PC410 l User’s Manual
10
1.2 Hardware Specification
Chapter 1: Product Introductions
Processor System
• 7
th
Gen Intel® Core™ i5 / i3 Processor with AMI 128Mbit
SPI BIOS
- Intel® Core™ i5-7300U Processor, Dual Core, 3MB
Cache, up to 3.5 GHz
- Intel® Core™ i3-7100U Processor, Dual Core, 3MB
Cache, 2.4 GHz
Memory
• 1x 260-Pin DDR4 1866/2133MHz SODIMM. Max. up to
16GB
Display
Triple Display
• 1x VGA
• 1x DisplayPort
• 1x Dual Channel 24 bit LVDS
Expansion
• 2x Full-size Mini PCIe Socket for Wi-Fi / GSM / Expansion
Module
• 1x Universal I/O Bracket (PC410 only)
Ethernet
• 1x Intel® i219LM GbE LAN Port, Support Wake-on-LAN
and PXE
• 1x Intel® I210-AT GbE LAN Port, Support Wake-on-LAN
and PXE
Audio
• Codec: Realtek ALC888S
• 1x Mic-in and 1x Line-out
Watchdog Timer
• Software Programmable Supports 1~255 sec. System
Reset
Storage
• 1x Removable 2.5" SATA HDD Bay, support RAID 0, 1
• 1x mSATA (shared by 1x Mini-PCIe)
• 1x Cfast (shared by 1x mSATA)
• 2x External SIM Card Socket
I/O Ports
• 4x USB 3.0 Port
• 8x Isolated DI and 8x Isolated DO Port
• 4x External DB9 for COM1~4, Support RS232/422/485
with Auto Flow Control
• 2x Internal COM5~6, Support RS232/422/485 with Auto
Flow Control (PC410 only)
• 3x Antenna Hole (PC400 only)
• 4x Antenna Hole (PC410 only)
• 1x AT/ATX Switch
• 1x Remote Power on/off Connector
Digital Input & Output
• 8x Digital Input (Source Type)
- Input Voltage (Dry Contact):
Logic 0: Close to GND
Logic 1: Open
- Input Voltage:
Logic 0: 3V max.
Logic 1: 5V min. (DI to COM-)
• 8x Digital Output
- Supply Voltage: 5~30VDC
- Sink Current: 200 mA Max. Per Channel
Power
• Support AT, ATX Mode
• 1x 3-pin Terminal Block Connector with Power Input
9~48VDC
• Power Ignition Sensing
• 1x Optional AC/DC 12V/5A, 60W Power Adapter
Environment
• Operating Temperature: Ambient with Air Flow:
-40°C to 70°C (with Industrial Grade Peripherals)
• Storage Temperature: -40°C to 85°C
• Relative humidity: 10%~95% (non-condensing)
Physical
• PC400 Series
- Dimension (WxDxH, mm): 246 x 220 x 42mm
- Weight: 1.57 kg
• PC410 Series
- Dimension (WxDxH, mm): 246 x 220 x 64mm
- Weight: 1.86 kg
• Construction: Extruded Aluminum with Heavy Duty
Metal
• Mounting: VESA Mounting Holes 75 x 75mm, 100 x
100mm
Operating System
• Windows 10
• Linux kernel 4.X
Certifications
• CE
• FCC Class A
