PC400 / PC410 l
User’s Manual
4.3.5 T
rusted
Comput
ing
■
Secur
ity Device Support
Enable or disable Security Device Support.
4.3.6 ACPI
Settings
■
En
able ACPI Auto Configura
tion
Enable or disable ACPI Auto Configur
ation.
51
Chapter 4: BIOS Se
tup
50
