Canon 40D Digital Camera Overview Manual
Page 30 © 2008 Consumer Programs Incorporated July 10, 2008
PROPRIETARY & CONFIDENTIAL
CANON DIGITAL CAMERA – SIDE
LABEL NAME PURPOSE
A Lens Hood Prevents lens flare
B Lens Camera Lens
C AF-MF Switch Sets camera to Auto-Focus Mode
D Mode Dial Camera Mode – Should be set to C3
E Flash-Sync Cable Sends signal to fire flash when a portrait is taken
F Eyepiece Camera Sends live view signal to Live-View monitor
G Video Cable Sends video signal to the Post-View Monitor
H Trip Cord Camera Trip Cord connection
