Canon CINEMA EOS SYSTEM - EU-V2 Expansion Unit 2

ADDED FUNCTIONALITY AND LENS COMPATIBILITY
28
EN
EU-V2 Expansion Unit 2
This expansion unit offers additional terminals and controls that add functionality to the camera. These
include: a V-lock mount for commercially available large-capacity batteries, menu operation buttons and
joystick (including one assignable button), Genlock synchronization, advanced remote control (circular
8-pin jack), wired network (Ethernet) functionality, additional audio inputs and controls, lens communication
(12-pin serial) and power outputs.
Depending on the terminal/function used, power is supplied either from the camera, or from a
commercially available V-mount battery attached to the EU-V2.
Supplied Accessories
 Connector cover
 M4 hex socket head bolts (x4)
Expansion unit
connector
(attach directly)
V-mount battery
(commercially available)
