ADDED FUNCTIONALITY AND LENS COMPATIBILITY
33
EN
Specifications
* All dimensions and weights are approximate.
INPUT 3, INPUT 4 terminals XLR 3-pin jack (pin1: shield, pin2: hot, pin3: cold), 2 sets, balanced
Sensitivity:
MIC setting: –60 dBu (volume center, full scale –18 dB) / 600 Ω,
microphone attenuator: 20 dB
LINE setting: 4 dBu (volume center, full scale –18 dB) / 10 kΩ
G-LOCK/SYNC OUT terminal BNC jack, 1.0 Vp-p / 75 Ω
G-LOCK (Genlock) setting: input only
SYNC OUT setting: output only, tri-level HD signal
The terminal’s function can be changed using the camera’s menu.
REMOTE B terminal Circular 8-pin jack (for the optional RC-V100 Remote Controller, RS-422
interface)
(Ethernet) terminal Ethernet, 1000BASE-T compatible
LENS terminal Circular 12-pin jack (12-pin serial interface)
DC OUT 24V 2A terminal Fischer 3-pin connector, rated output: 24 V DC, maximum current: 2.0 A
D-TAP terminal D-Tap connector, maximum output: 50 W (nominal)
Operating temperature 0 °C – 40 °C (32 °F – 104 °F)
Dimensions* (W x H x D) 117 x 147 x 117 mm (4.6 x 5.8 x 4.6 in.)
Weight* (without connector cover) 654 g (1.4 lb.)
