Canon EOS 760D - Connection Via WPS (PBC Mode)

71
This is a connection mode available when using an access point
compatible with WPS. In pushbutton connection mode (PBC mode), the
camera and the access point can be connected simply by pressing the
WPS button on the access point.
If multiple access points are active in the surrounding area, it may be
more difficult to establish a connection. In such a case, try using
[WPS (PIN mode)] to establish a connection.
Check the position of the WPS button on the access point in
advance.
It may take approx. one minute to establish a connection.
1
Select [Wi-Fi function].
Under the [51] tab, set [Wi-Fi/NFC]
to [Enable], then select [Wi-Fi
function].
2
Select an item.
Select either [q], [l] or [o], then
press <0>.
3
Select [Infrastructure mode].
Displayed when [q] or [l] is
selected. Go to step 4 when selecting
[o].
Press the <W> <X> keys to select
[Infrastructure mode], then press
<0>.
Select [OK] and press <0> to go to
the next screen.
Connection via WPS (PBC Mode)
