130
The camera’s AF sensor has 45 AF points. The illustration below shows
the AF sensor pattern corresponding to each AF point. When using
lenses with a maximum aperture of f/2.8 or faster, high-precision AF is
possible at the viewfinder center.
AF Sensor
This focusing sensor is geared to obtain higher precision
focusing for lenses with a maximum aperture of f/2.8 or
faster. A diagonal cross pattern makes it easier to focus on
the subjects that may be difficult to focus. It is provided at
the center AF point.
These focusing sensors are geared for lenses with a
maximum aperture of f/5.6 or faster (and some supporting
f/8). Since they have a horizontal pattern, they can detect
vertical lines. They cover all 45 AF points.
These focusing sensors are geared for lenses with a
maximum aperture of f/5.6 or faster (and some supporting
f/8). Since they have a vertical pattern, they can detect
horizontal lines. They cover all 45 AF points.
Depending on the lens used, the number of usable AF points, AF point
patterns, Area AF frame shape, etc. vary. For details, see “Lenses and
Usable AF Points” on page 131.
Diagram
Cross-type focusing: f/5.6 vertical + f/5.6 horizontal
(some also supporting f/8)
Dual cross-type focusing:
f/2.8 right diagonal + f/2.8 left diagonal
f/5.6 vertical + f/5.6 horizontal
(also supporting f/8)

Canon EOS 800D Specifications

General

Camera Type	Digital SLR
Sensor	CMOS
Sensor Size	22.3 x 14.9 mm
Image Processor	DIGIC 7
ISO Range	100-25600 (expandable to 51200)
Autofocus Points	45-point all cross-type
Continuous Shooting Speed	6 fps
Lens Mount	Canon EF/EF-S
Video Resolution	Full HD 1080p at 60 fps
Screen	3.0-inch Vari-Angle Touchscreen LCD
Screen Resolution	1, 040, 000 dots
Viewfinder	Optical (pentamirror)
Connectivity	Wi-Fi, NFC, Bluetooth
Battery	LP-E17
Shutter Speed	30-1/4000 sec
Image Stabilization	Lens-based
Battery Life	Approx. 600 shots
Dimensions	131.0 x 99.9 x 76.2 mm
