Built-in flash/AF-assist beam emitter
(p.204/121)
<k> Wi-Fi lamp
<g> ISO speed
setting button (p.152)
<6> Main Dial
Shutter button
(p.52)
Remote
control sensor
(p.200, 412)
Grip
Mirror (p.200, 331)
Contacts (p.27)
Lens mount
Lens lock pin
<Y> External microphone IN
terminal (p.301)
<F> Remote control terminal (p.413)
<D> HDMI mini OUT terminal (p.357)
Depth-of-field preview
button (p.190)
Lens release button
(p.50)
Red-eye
reduction/
Self-timer
lamp
(p.205/143)
EF lens mount index (p.49)
Built-in
microphones
(p.264)
Flash sync contacts
Hot shoe (p.209)
<D> Flash button
(p.204)
Speaker
(p.350)
Strap mount
(p.35)
Body cap (p.49)
EF-S lens mount index
(p.49)
Terminal cover
<B> AF area selection
button (p.124)
<U> Display
button (p.71)
p (N-Mark)*
<I> Digital terminal (p.477)
* Used for Wi-Fi connections
via the NFC function.
<V> Focal plane mark
(p.93)
Mode Dial (p.30)
Power switch (p.43)
