H. Field Replacement Parts
Field replacement parts have a limited life and are expected to end during
a customer’s specific machine operations. They should be replaced as
needed by a Service Technician. Examples of field replacement parts may
include, but are not limited to the linear scale and carriage unit. To assist
in the initial parts planning, the table below lists the estimated parts life.
Note: All replacement parts shown in the tables below are for reference
purposes only and are subject to change without notice.
Table 10 - imagePROGRAF iPF6400S Field Replacement Parts List
Part Name
Part Number
1
Quantity
Estimated Life
(A0
1
Carriage Unit
Sheets)
QM4-8017-000
1 14,000
Encoder Sensor Unit QM2-3421-010 1 14,000
Scale, Linear QC3-1882-000 1 14,000
Multisensor Unit QM4-8018-000 1 14,000
Purge Unit QM3-8145-000 1 14,000
Head Management
Sensor Unit
QM3-0529-000 1 14,000
Motor, DC, Brushless QK1-2083-000 1 14,000
Motor, 26.4V, DC QK1-0447-000 1 14,000
Suction Fan Unit QM3-0701-010 1 14,000
Mist Fan Unit QM3-0807-000 1 14,000
Cutter QM3-8149-010 1 14,000
Absorber, Ink, Fan QC2-1100-000 1 14,000
Absorber, Ink, Waste QC2-0807-000 1 14,000
Waste Ink Absorber QC2-0807-000 1 14,000
