K. Maintenance Kit
Canon USA has prepared an imagePROGRAF iPF6400S Maintenance Kit
to enhance the durability of the printer, while reducing operating costs.
Reduced printer downtime can be achieved when the Maintenance Kit is
utilized. The printer’s built-in counters and warning messages inform end-
users when the maintenance kit is required.
Table 12 - imagePROGRAF iPF6400S Maintenance Kit Parts List
Kit Parts
Number
1
Unit Name
Replacement
Part Number
1
Description
QY6-1530-
000
Wia1
Wib1
QM3-0800-000
Duct Unit, Platen
QM3-0701-000 Suction Fan Unit
CR1 to
CR5
QM4-8091-000
Carriage Unit
QD1-0404-000
Lever, R, Tube
QD1-0405-000
Lever, L, Tube
QC2-0661-000
Link, Lever, Tube
QC2-1396-000
Spring, Tension
QC2-0664-000
Pad, Oil
QC2-0663-000 Holder, Wire (mech)
QM3-0543-000
Cleaner Unit, R, Rail,
Carriage
QM3-0542-000
Cleaner Unit, L, Rail,
Carriage
QM2-3421-000
Encoder Sensor Unit
QC3-1882-000
Scale, Linear
QC3-2664-000
Cam, LIETER×2
SP1
QM4-8366-000
Ink Supply Unit (F)
QM4-8367-000
Ink Supply Unit (R)
L. End-User Periodic Maintenance
In accordance with the user’s manual, the end-user is expected to maintain
the following areas of the printer:
• Printhead cleaning (using the operation panel)
• Replacement of Printheads, ink tanks, and filters
• Cleaning of ink mist and other substances around external covers and
output basket area (dry the surfaces after wiping with a damp cloth)
1
Item Numbers and Part Numbers are subject to change due to engineering changes, etc.
