imagePROGRAF iPF6400S Service Guide
imagePROGRAF iPF6400S Service Guide September 2013
Page 37
Table 16 – Printhead PF-05 Specifications
Printhead PF-05
Model PF-05
Type Bubble-jet on demand
Head configuration 6 colors integrated type (6 chips per print head x 2 print heads)
Nozzle pitch 1,200 dpi x 2
Nozzle per chip
MBK/BK/M/Y: 2,560 nozzles for each color
C/PC/PM/GY: 5,120 nozzles for each color
Droplet size 4 picoliters per color
Head replacement User replacement
Table 17 – X-Rite Spectrophotometer Unit SU-21 Specifications
Item Specification
Size Approximately 101.3mm (D) x 63mm (W) x 51.2mm (H), 145g
Measuring Conditions Approximately 0°- 45° Ring light-receiving type
Light Source Conditions
Tungsten + LED lamp
Possible to switch UV-cut/non-UV-cut
ISO13655(2009) M1/M2Condition
Output Data Approximately 400nm to 700nm (10nm intervals), XYZ, Lab
Light Source A, C, D50, D55, D65, D75, F2, F7, F8, F10, F11, F12
Standard View Angle Approximately 2°, 10°
Lifetime 430,000 measurement *Ref. value
Maintenance Annual calibration by manufacturer is recommended.
Sensor Accuracy
Repeating accuracy: Max. ∆Ecmc≤0.2@White(tile)
Max. ∆Ecmc≤0.6@Black (tile)
Difference among units: Max.∆Ecmc≤1.0@BCRA
Avg. ∆Ecmc≤0.5@BCRA
Bundled Products Sensor main body, calibration white tile, calibration certificate
